PFW 6810 Display Wall Mount tilt

  • Easy levelling and installation
  • For the heaviest displays
  • Self-centering display bolts
  • Integrated lock
  • Locked service position

The PFW 6810 is a sturdy and at the same time elegant tilt wall mount. It features an aesthetically integrated lock on top of the ability to tilt up to 15°. The mount can hold displays from 55 to 80 inch, weighing up to 75 kg

PFW 6810 Display Wall Mount tilt

Videos

Product video
Mounting instruction video

Awards and certificates

This product passed extensive tests to guarantee compliance with the TÜV Nord quality standard. Products are tested to carry at least 3 times the indicated weight for domestic related products and at least 5 times for professional products without collapsing. TÜV NORD is an independent certification authority and recognized globally as the label of excellent quality.

Fischer inside

Fischer plugs inside

Specifications For PFW 6810 Display Wall Mount tilt

EAN single box
8712285334184
Series
PFW 6000 Series
Product group
Display mount tilt
Guarantee
5 years
TÜV certified
Yes
Colour
Black
Min. screen size (inch)
55
Max. screen size (inch)
80
Max. weight load (kg)
75
Max. weight load (lbs)
165.35
Tilt
Tilt up to 15°
Orientation
Landscape
Hole pattern (VESA)
  • 75 mm x 75 mm
  • 100 mm x 100 mm
  • 100 mm x 200 mm
  • 200 mm x 100 mm
  • 200 mm x 200 mm
  • 300 mm x 200 mm
  • 300 mm x 300 mm
  • 400 mm x 200 mm
  • 400 mm x 300 mm
  • 400 mm x 400 mm
  • 500 mm x 200 mm
  • 500 mm x 300 mm
  • 500 mm x 400 mm
  • 600 mm x 200 mm
  • 600 mm x 300 mm
  • 600 mm x 400 mm
  • 700 mm x 400 mm
  • 800 mm x 400 mm
Lock options
Lock included / integrated
Levelling function
Post-installation horizontal levelling
Fischer inside
Yes
Service position
Yes
Min. horizontal hole pattern (mm)
75
Max. horizontal hole pattern (mm)
800
Min. vertical hole pattern (mm)
75
Max. vertical hole pattern (mm)
400
Min. distance to the wall (mm)
52
Min. distance to the wall (inch)
2.05
